| 中央處理器 | I5-11500 |
| 處理器數量(標準/最大) | 支援單顆 Intel®處理器 |
| 晶片組 | Intel® W580 Chipset |
| 作業系統 | Windows 11 Pro |
| 記憶體 | 16G NON-ECC DDR4-3200 |
|
記憶體插槽數量/ 已佔用數量 |
總 Slots 數 : 4 (2 通道) 總容量 : 最大至 128GB UDIMM 記憶體類型 : 雙通道 DDR4 2933/2666 non ECC and with ECC 記憶體大小: 32GB, 16GB, 8GB UDIMM |
| 硬碟機 | 1TB |
| 硬碟機數量(標準/最大) | 1x internal 2.5” drive bay 3x internal 3.5” drive bay (or 3x internal 2.5” drive bay: optional cage required) 2x internal 2.5”/3.5” drive bay (optional cage required) |
| 光碟機 | DVD-RW |
| 磁碟控制器 | SATA 控制器: Intel® W580 Chipset 8 x SATA3 6Gb/s 連接埠 Intel® Rapid Storage Technology(RST) (For Windows Only) (Support Software RAID 0, 1, 5, 10 ) 1 x M.2_1 socket3, up to 2280 type (SATA mode & PCIe Gen3 x4 link) 1 x M.2_2 socket3, up to 22110 type (PCIe Gen4 x4 link) |
| 顯示晶片 | CPU Integrated (Intel UHD) Multi-VGA output support: DVI-D/HDMI/DisplayPort/VGA - Supports DVI-D with Max resolution 1920 x 1200@60 Hz - Supports HDMI 1.4 with Max resolution 4096 x 2160@24 Hz - Supports DisplayPort 1.2 with Max resolution 4096 x 2304@60 Hz - Supports VGA with Max resolution 1920 x 1200@60 Hz |
| I/O傳輸介面 | 前面板: 1 x USB 3.2 Gen2x2 port 2 x USB 3.2 Gen1 ports 1 x USB 2.0 port 1 x Headphone port 1 x Microphone port 後面板: 2 x USB 3.2 Gen2 ports (1 port at Type A, 1 port at Type C) 4 x USB 3.2 Gen1 ports 1 x HDMI 1 x DisplayPort 1 x DVI-D 1 x VGA 2 x LAN ports (RJ45) 1 x 7.1-channel Audio I/O ports (5+1 Audio jacks) |
| 網路功能 | 2 x Intel® I225-LM 2.5GbE LAN (2.5G) |
| 擴充槽數量 | Total: 5 Location-1: PCIe x16 slots (Gen4 x16/x8 link, FH, FL) Location-2: PCIe x1 slots (Gen3 x1 link, FH, FL) Location-3: PCIe x16 slots (Gen4 x0/x8 link, FH, FL) Location-5: PCIe x16 slots (Gen4 x4 link, FH, FL) Location-6: PCIe x16 slots (Gen3 x4 link, FH, FL) * the bandwidth of PCIe link is shared with M.2_2 |
| 尺寸 | 423mm x 190mm x 435mm |
| 電源供應器 | 300W 80+ |
| 機構型式 | WorkStation 工作站 |
| 輸入裝置 | USB 鍵盤及滑鼠 |
| 保固期限 | 3-3-3(零件/人工/隔日到府) |
| 安規 | BSMI, CE, FCC(Class B), Energy Star |
