| 中央處理器 | I7-13700 |
| 處理器數量(標準/最大) | 支援單顆 Intel®處理器 |
| 晶片組 | Intel® W680 Chipset |
| 作業系統 | Windows 11 Pro |
| 記憶體 | 16G NON-ECC DDR5-4800 |
| 記憶體插槽數量/已佔用數量 | Total Slots : 4 (2-channel) Capacity : Maximum up to 128GB UDIMM Memory Type : Dual Channel DDR5 4800 non ECC and with ECC Memory Size : 32GB, 16GB, 8GB UDIMM |
| 硬碟機 | 1TB SSD |
| 硬碟機數量(標準/最大) | 3 x internal 3.5” Drive bays 1 x Internal 2.5" Drive bay |
| 光碟機 | DVD-RW |
| 磁碟控制器 | Storage Controller : Intel® W680 Chipset 8 x SATA3 6Gb/s ports Intel® Rapid Storage Technology(RST) (For Windows Only) (Support Software RAID 0, 1, 5, 10 ) 1 x M.2_1 socket3, up to 2280 type (PCIe Gen4 x4 link), from CPU 1 x M.2_2 socket3, up to 2280 type (PCIe Gen3 x4 link), from PCH 1 x M.2_3 socket3, up to 22110 type (PCIe Gen4 x4 link), from PCH |
| 顯示晶片 | Up to 1 GPU Card |
| I/O傳輸介面 | (前面板) 1 x USB 3.2 Gen2x2 port 2 x USB 3.2 Gen1 ports 1 x USB 2.0 port 1 x Headphone port 1 x Microphone port (後面板) 2 x USB 3.2 Gen2 ports (1 port at Type A, 1 port at Type C) 4 x USB 3.2 Gen1 ports 1 x HDMI 1 x DisplayPort 1 x DVI-D 1 x VGA 2 x LAN ports (RJ45) 1 x 7.1-channel Audio I/O ports (5+1 Audio jacks) |
| 網路功能 | 2 x Intel® I225-LM 2.5GbE LAN |
| 擴充槽數量 | Total: 5 Location-1: PCIe x16 slots (Gen5 x16/x8 link, FH, FL) Location-2: PCIe x1 slots (Gen3 x1 link, FH, FL) Location-3: PCIe x16 slots (Gen5 x0/x8 link, FH, FL) Location-5: PCIe x16 slots (Gen4 x4 link, FH, FL)*1 Location-6: PCIe x16 slots (Gen3 x4 link, FH, FL) *1 the bandwidth of PCIe link is shared with M.2_2 |
| 尺寸 | 423mm x 190mm x 435mm 16.7" x 7.48" x 17.1" |
| 重量 | Net Weight : 9.9 KG Gross Weight : 12.1 KG |
| 電源供應器 | 550W 80+ Gold |
| 機構型式 | WorkStation 工作站 |
| 附贈軟體 | USB鍵盤/USB滑鼠/防毒 |
| 保固期限 | 3-3-3(零件/人工/隔日到府) |
| 安規 | BSMI, CE, FCC, Energy Star |
