機構型式 | 直立式電腦 |
中央處理器 | Intel® Core™ i3-13100, 4C (4P + 0E) / 8T, P-core 3.4 / 4.5GHz, 12MB |
作業系統 | Windows 11 Pro |
記憶體(標準/插槽/最大) |
1x 8GB UDIMM DDR4-3200 插槽: Two DDR4 UDIMM slots, dual-channel capable 最大擴充到64GB DDR4-3200 |
硬碟 | 256GB SSD M.2 + 1TB HDD 7200rpm |
顯示晶片 | Intel® UHD Graphics 730 |
光碟機 | DVD±RW |
主機板晶片 | Intel® B760 Chipset |
讀卡機 | 3-in-1 Card Reader |
音效裝置 | 高清(HD) 音訊、Realtek ALC222-CG codec、揚聲器2Wx1 |
網路 | Intel® I219-V, 1x RJ45 |
擴充槽數量 (PCI/PCI-express) | One PCIe® 4.0 x16, full-height, half-length, Two PCIe® 3.0 x1, full-height, half-length, Two M.2 slots (one for WLAN, one for SSD) |
擴充空間 |
Front Ports: 1x USB-C® 3.2 Gen 1 (support data transfer and 5V@3A charging), 2x USB 3.2 Gen 1, 2x USB 3.2 Gen 2, 1x headphone / microphone combo jack (3.5mm), 1x microphone (3.5mm) Rear Ports: 4x USB 2.0 (one supports Smart Power On), 1x HDMI® 1.4b, 1x DisplayPort™ 1.4, 1x VGA, 1x Ethernet (RJ-45), 1x headphone (3.5mm), 1x serial (9-pin) |
電源供應器 | 260W 90% |
保固期限 | 3Y Onsite |
尺寸 | 145 x 294 x 340 mm |
